Feature:
1. Suit to paper,LDPE film,HDPE film,LLDPE film,BOPP film,PP film,PET film,
2.Edge position control and automatic tension control
3.meter account,machine can stop automatic
4.Machine power 220V,380V,440V,480V
5.Afford after sale service,can send engineer to buyer factory,to install machine and afford training service.
6.We are welcomed customers Customized machines or OEM design.
Main Technical Parameter：
| Model | WFQ-B1100 | WFQ-B1300 | WFQ-B1600 |
| Max.width of unwinding | 1100mm | 1300mm | 1600mm |
| Max.diameter of unwinding | Φ1400mm | Φ1400mm | Φ1400mm |
| Min.width of slitting | 20mm | 20mm | 20mm |
| Max.diameter of rewinding | Φ500mm | Φ500mm | Φ500mm |
| Max.Speed | 200m/min | 200m/min | 200m/min |
| Precision of slitting | ±0.2mm | ±0.2mm | ±0.2mm |
| Total Power | 7kw | 7kw | 8.5kw |
| Suitable power supply | 380V/50Hz | 380V/50Hz | 380V/50Hz |
| Weight(approx) | 2100kg | 2300kg | 2600kg |
| Overall dimension | 2850x2150x1350mm | 2850x2350x1350mm | 2850x2650x1350mm |
| Material | Paper,HDPE, LDPE, LLDPE,PET,BOPP,OPP,CPP film | ||
| Power Voltage | 220V,380V,440V,480V(Customized based on request,For example: USA 480V 60Hz, Mexico 440V/220V 60Hz, Saudi Arabia 380V 60Hz, Nigeria 415V 50Hz...) | ||
| Material Core Diameter | 76mm(3 inch) | ||
| Machine Working Time | 24 hours * 7 days | ||
| Warranty | 1 year | ||
| Technical Assistance | Engineers available to service machinery overseas | ||
※Correct specifications depend on the actual model. All specifications are subject to change without prior notice.
Our Main parts cooperator as following brand,but standard parts all made from China.
