Performance:
Easy operation,flexible starting,accurate color register.
the meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
Pneumatic printing cylinder lift and lower, is will stir the printing ink automatically after lifting .
the printing ink is spread by the anilox cylinder with even ink color.
Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
360°continuous and adjustable longitudinal register device.
The frequency control of motor speed adapts to different printing speeds.
There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
| YT-2600 | YT-2800 | YT-21000 | |
| Two color | Two color | Two color | |
| Max.Width of Printing Material | 600mm | 800mm | 1000mm |
| Max.Printing Width | 560mm | 760mm | 960mm |
| Length Range of Printed | 191-914mm | 191-914mm | 191-914mm |
| Max.Diameter of Roll Material | 450mm | 450mm | 450mm |
| Printing Speed | 5-50m/min | 5-50m/min | 5-50m/min |
| Thickness of plate(Including Two-sides Glue Paper) | 2.38mm | 2.38mm | 2.38mm |
| Total Power | 8Kw | 10Kw | 12Kw |
| Outline Dimension | 2300×190×2200mm | 2300×2100×2200mm | 2300×2300×2200mm |
Our Main parts cooperator as following brand,but standard parts all made from China.
